Description
-
- rame
-
500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
- Fork
- Weight
- ML – 8.11 kg/17.88 lb (with TLR sealant, no tubes)
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
- Battery
-
SRAM AXS battery pack (with charger)
- *Shifter
-
Size: XS, S, M, ML, L, XL
SRAM Rival AXS E1Size: XS, S, M, ML, L, XL
SRAM Rival AXS, 12-speed - Front derailleur
-
SRAM Rival AXS, braze-on
- Rear derailleur
-
SRAM Rival AXS, 36T max cog
- *Crank
-
Size: XS, S, M, ML
SRAM Rival AXS, 48/35, DUB, 165 mm lengthSize: XS, S
SRAM Rival AXS E1, 48/35, DUB, 160mm lengthSize: L, XL
SRAM Rival AXS, 48/35, DUB, 170 mm lengthSize: L, XL
SRAM Rival AXS, 48/35, DUB, 172.5 mm length - Bottom bracket
-
SRAM DUB, T47 threaded, internal bearing
- Cassette
-
SRAM XG-1250, 10-36, 12-speed
- Max. chainring size
- 1x: 54T, 2x: 56/43
- Wheel front
-
Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 100x12 mm thru axle
- Wheel rear
-
Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 50 mm rim depth, Sram XDR freehub, 142x12 mm thru axle
- Skewer front
- Skewer rear
- Tyre
- Tyre part
-
Bontrager TLR sealant, 180 ml/6 oz
- Rim strip
- Max tyre size
- 32mm (as measured, see manual for details)
- Saddle
- Seatpost
-
Madone aero carbon seat post, 0 mm offset, short length
- *Handlebar
-
Size: XS
Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36 cm control width, 40 cm drop widthSize: S, M
Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop widthSize: ML, L
Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop widthSize: XL
Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width - Handlebar tape
- *Stem
- Brake rotor
-
SRAM Paceline, rounded, CentreLock, 160 mm
- Rotor size
- Max brake rotor sizes: 180 mm front, 160 mm rear
